Rugged Tablet

Budget-friendly IP67 Rugged Windows® Tablet

Contact Sales
RUGSTORM R100 10.1" Windows rugged tablet
Front View of Rugged Tablet R100 Back View of Rugged Tablet R100 Top View of Rugged Tablet R100 Bottom View of Rugged Tablet R100 Left View of Rugged Tablet R100 Right View of Rugged Tablet R100
Front View of Rugged Tablet R100
Back View of Rugged Tablet R100
Top View of Rugged Tablet R100
Bottom View of Rugged Tablet R100
Left View of Rugged Tablet R100
Right View of Rugged Tablet R100

Rugged Tablet

「R100」10.1-inch Rugged Tablet

Rugged Tablet R100 is a budget-friendly IP67 rugged tablet, offering versatile I/O ports, wide-ranging connectivity, and optional barcode scanning. Easily adaptable to any demanding environment, the R100 is your ideal choice for cost-effective rugged solutions.

  • OS: Windows® 11 IoT Enterprise
  • CPU: Intel® Pentium® N6415
  • Display: 10.1-inch, 1920 x 1200 resolution
  • Memory: 8GB LPDDR4X
  • Storage: 128GB eMMC / 256GB SSD / 512GB SSD
  • Sealing: IP67 & MIL-STD-810H
  • Connectivity: Wi-Fi 6E, Bluetooth V5.3, optional 4G LTE
  • Security: TPM 2.0

  • Compliance certifications will be tailored to customer requirements.
Spec Sheet Resource Contact Sales

Always Stay Powered Up

Enjoy uninterrupted power without compromising protection. The Rugged Tablet R100’s removable battery design and rugged construction make it perfect for demanding tasks that require extended use.

IP67-rated Protection

Offering IP67 water and dust resistance even with a battery removable design, the Rugged Tablet R100 redefines durability with flexibility and makes sure you stay productive no matter the conditions.

Unlock Possibilities with Flexible I/O ports

The Rugged Tablet R100 is more than just a rugged device. With its multiple flexible I/O ports and optional barcode scanner, it’s a versatile tool that can be tailored to your exact requirements, regardless of your work environment.

Slim & Lightweight

Experience the convenience of a rugged tablet without the bulk. The Rugged Tablet R100’s lightweight design and sleek profile, combined with specialized accessories, make it the perfect companion for professionals who need a durable and versatile device.

Accuracy to Centimeter

Equipped with a built-in GNSS module, the Rugged Tablet R100 delivers precise centimeter-level positioning data, making it your most reliable partner for timely location information.

Enterprise-grade Data Security

The Rugged Tablet R100 features a built-in Trusted Platform Module (TPM 2.0), configured by default for robust enterprise-grade data protection. This secure hardware and software environment safeguards all operational and wireless communication information.

Operation System
  • Windows® 11 loT Enterprise SAC 64 bit
Processor
  • Intel® Pentium® N6415,1.2 GHz up to 3.0 GHz
Memory & Storage
  • 8 GB LPDDR4X
  • 128 GB eMMC
    • Optional 256 GB SSD
    • Optional 512 GB SSD
Display
  • 10.1″ 1920 x 1200 resolution
  • 10-point touch (Support wet hand & glove operation modes)
  • 800 nits typical
  • Direct bonding
Sensors
  • Ambient light sensor
  • G-sensor
Audio
  • 95db speaker (10 cm, 1 kHz)
  • Built-in microphone
Camera
  • 5 MP rear camera with autofocus and flashlight
  • 2 MP front camera
Interface
  • 1 x USB2.0 Type-C (Charging 20V, 3.25A)
  • 1 x USB3.1 Type-C (Charging, HDMI)
  • 1 x USB3.1 Type-A
  • 1 x USB2.0 Type-A
  • 1 x RJ45 10/100M/1000M
  • 1 x Micro SDXC (Max: 1 TB) slot
  • 1 x Nano SIM Card slot
  • 1 x 3.5mm Audio jack
  • Back docking connector 14-pin (USB3.0)
  • Docking connector 7-pin (Charing, USB2.0)
  • Barcode scanning engine Honeywell N4680 (Optional)
  • Buttons
    • 1 x Power
    • 1 x Lock/Unlock screen (programmable)
    • 1 x Home (programmable)
    • 1 x F1 button: Flashlight (programmable)
    • 1 x F2 button: Volume + (programmable)
    • 1 x F3 button: Volume – (programmable)
    • 1 x “+” button: Brightness + (programmable)
    • 1 x “-” button: Brightness – (programmable)
  • Status indicators
    • 1 x Power
    • 1 x Battery
    • 1 x Front camera
Dimension & Weight
  • 260mm L x 173mm W x 16.7mm D/10.2″ L x 6.8″ W x 0.79″ D
  • 1kg/2.2lbs
Power
  • 7.6V, 4200mAh typical
  • Not less than 4 hours working time (JEITA3.0)
  • AC/DC adapter: Input AC 100-240V 50~60 Hz; Output DC 20V, 3.25A
Wireless Connectivity
  • Wi-Fi (WLAN)
    • 802.11 a/b/g/n/ac/ax 2.4,5,6GHz, support Wi-Fi 6E
  • Bluetooth (WPAN)
    • v5.3
  • Cellular (WWAN)
    • optional 4G LTE Global version
  • GNSS
    • GPS
    • Galileo
    • BeiDou
    • GLONASS
Security
  • TPM v2.0
Environment & Ruggedness
  • Operating temperature
    • -10°C to 60°C/14°F to 140°F
  •  Storage temperature
    • -40°C to 70°C/-40°F to 158°F
  •  Humidity
    • 0% to 95% non-condensing
  • Sealing
    • IP67
  • MIL-STD-810H Method 516.8 1.2m/4’
Certifications
  • CE, RoHS, REACH
  • WEEE
  • FCC
  • CCC
Optional Accessory
  • Battery Charger
  • Battery
  • Shoulder Strap
  • Hand Strap
RUGSTORM offers a wide range of certifications across multiple countries. For more information, please contact us at [email protected].



Accessory Guide
    Hand Strap
    Compatible Model: R100
    Packaged screws
    Velcro strap for battery swap
    Battery Charger
    Compatible Model: R100
    Dual-slot charging dock
    19V DC in
    Expansion Battery
    Compatible Model: R80, R100
    7.6V, typ. 4200mAh
    Lithium-ion Battery, 2S1P
    Adaptor
    Compatible Model: R100
    65W Max USB-C charger
    US plug / NEMA plug
    Adaptor
    Compatible Model: R100
    65W Max USB-C charger
    EU plug / Schuko plug
