RUGSTORM Vehicle Display VD100 is a vehicle‑mount display engineered for heavy vehicles and industrial machinery. It features built‑in high‑precision GNSS and IP65/EP455‑rated protection, and integrates seamlessly with onboard systems while supporting a wide range of data transmission needs. This makes the VD100 ideal for navigation, equipment monitoring, and heavy‑duty control applications.
Vehicle Display
Equipped with a 10.1″ sunlight‑readable touchscreen, the VD100 delivers sharp, bright visuals that remain clear under direct sunlight or in challenging weather. Operators can count on consistent visibility and responsive touch control, keeping productivity high in demanding field conditions.
Featuring Wi‑Fi, Bluetooth, 4G LTE, GNSS, and CANbus support alongside versatile I/O ports, the VD100 offers seamless connectivity to navigation systems, sensors, and fleet management tools. This ensures smooth data transmission and easy integration, making it a powerful hub for connected vehicle operations.
The VD100 is purpose‑engineered to handle the toughest conditions in mining, construction, agriculture, and logistics fleets. With IP65 sealing and rugged certification, it resists vibration, dust, and moisture, ensuring reliable operation even in harsh outdoor environments where ordinary devices fail.
RUGSTORM combines 15+ years of ODM experience with its own factory and in‑house laboratory to deliver fast, scalable, and highly customized solutions.
With complete control over design, engineering, manufacturing, and after‑sales support, RUGSTORM transforms complex requirements into streamlined, cost‑effective products.
From custom I/O and tailored firmware to mechanical adjustments and branded finishes, every modification is precise, reliable, and purpose‑built to fit seamlessly into your workflow.
| Category | Feature | Detailed Specifications |
|---|---|---|
| System & Performance | Operating System | Android 10.0 |
| Processor | Allwinner T507 Quad-core 1.4GHz | |
| Memory | 4GB LPDDR | |
| Storage | 32GB eMMC | |
| Display | Size & Resolution | 10.1-inch, 1024×600 resolution |
| Brightness | 750 nits typical | |
| Touch Panel | 10-point capacitive touch | |
| supports wet & glove operation modes | ||
| Optics | Direct bonding | |
| Connectivity & I/O Ports | I/O Ports | 1 x 14 Pin Connector |
| 1 x CAN | ||
| 1 x RS232 | ||
| 4 x AHD | ||
| 1 x Micro-USB 2.0 Device | ||
| 1 x USB 2.0 Type-A Host | ||
| 1 x 10M/100M Ethernet | ||
| Antenna Ports | 1 x TNC Female (GNSS) | |
| 1 x SMA Female (4G LTE) | ||
| Expansion | 1 x Micro SDXC slot (supports up to 128GB) | |
| 1 x SIM card slot | ||
| Wireless Communication | WLAN | Wi-Fi IEEE 802.11 b/g/n 2.4GHz |
| WWAN (Cellular) | 4G LTE Global version | |
| Bluetooth | v5.4 | |
| GNSS | GPS / Galileo / BeiDou / GLONASS | |
| Power & Audio | Power Input | 9V-36V |
| Audio | 95dB Speaker, 1kHz | |
| Ruggedness & Environment | Ingress Protection | IP65 |
| Shock & Vibration | EP455 | |
| Operating Temp. | -20°C to 70°C | |
| Storage Temp. | -30°C to 85°C | |
| Humidity | 0%~95% (non-condensing) | |
| Physical Characteristics | Dimensions | 269.0mm(L) x 190.0mm(W) x 41.0mm(D) |
| Weight | 1.25kg | |
| Certifications | Rugstorm holds a wide range of certifications across multiple countries. For more information, please contact us at [email protected] |
From the first sketch to the final assembly, we own the process. Our end-to-end factory operations mean we don’t just meet your specs—we perfect them, whether it’s a standard tweak or a full-scale custom build.
With hubs in Japan, China, and the Netherlands, we provide a seamless support bridge between Asia and Europe. You get the power of a global network with the responsiveness of a local partner.
Since 2019, we’ve operated in “no-fail” sectors like public safety and critical infrastructure. We don’t just build products, we build reliability that meets the world’s toughest standards.
| Category | Feature | Detailed Specifications |
| System & Performance | Operating System | Android 10.0 |
| Processor | Allwinner T507 Quad-core 1.4GHz | |
| Memory | 4GB LPDDR | |
| Storage | 32GB eMMC | |
| Display | Size & Resolution | 10.1-inch, 1024×600 resolution |
| Brightness | 750 nits typical | |
| Touch Panel | 10-point capacitive touch | |
| supports wet & glove operation modes | ||
| Optics | Direct bonding | |
| Connectivity & I/O Ports | I/O Ports | 1 x 14 Pin Connector |
| 1 x CAN | ||
| 1 x RS232 | ||
| 4 x AHD | ||
| 1 x Micro-USB 2.0 Device | ||
| 1 x USB 2.0 Type-A Host | ||
| 1 x 10M/100M Ethernet | ||
| Antenna Ports | 1 x TNC Female (GNSS) | |
| 1 x SMA Female (4G LTE) | ||
| Expansion | 1 x Micro SDXC slot (supports up to 128GB) | |
| 1 x SIM card slot | ||
| Wireless Communication | WLAN | Wi-Fi IEEE 802.11 b/g/n 2.4GHz |
| WWAN (Cellular) | 4G LTE Global version | |
| Bluetooth | v5.4 | |
| GNSS | GPS / Galileo / BeiDou / GLONASS | |
| Power & Audio | Power Input | 9V-36V |
| Audio | 95dB Speaker, 1kHz | |
| Ruggedness & Environment | Ingress Protection | IP65 |
| Shock & Vibration | EP455 | |
| Operating Temp. | -20°C to 70°C | |
| Storage Temp. | -30°C to 85°C | |
| Humidity | 0%~95% (non-condensing) | |
| Physical Characteristics | Dimensions | 269.0mm(L) x 190.0mm(W) x 41.0mm(D) |
| Weight | 1.25kg | |
| Certifications | Rugstorm holds a wide range of certifications across multiple countries. For more information, please contact us at [email protected] |
